Shallow Mount Planter 40 - Crash Tested to stop a 7500kg vehicle @ 40mph
- Warranty 12 month for product and installation
- Lead Time 5 Working Days
Installation Available UK-wide
- Sold Secure
- Insurance Approved
- UK-wide Installation
Product Overview
The Planter 40 is the world’s smallest crash-rated security planter, tested to BSI PAS 68 to stop a 7.5-tonne truck at speeds of up to 50mph (80kph)
The universal slimline planter is the world’s smallest crash-rated security planter and the only product of its kind that can be manufactured to any size required. Designed as a surface-mounted system with an ultra-shallow foundation, it avoids the need for costly utility diversions and is ideal for sites with restricted space.
Its slim profile makes it well suited for narrow walkways outside banks, train stations, stadiums, and other busy public areas, providing high-level security without taking up valuable floor space. Weighing only 100kg, the planter can be positioned without heavy lifting equipment, offering quick and simple installation. The minimum standard size is 1.48m in length and 450mm in width, with bespoke dimensions available to suit client requirements.
The planter has been crash tested to BSI PAS 68, proven to stop a 7.5-tonne truck travelling at 30mph (48kph), 40mph (64kph), or 50mph (80kph) at 90 degrees.
To explore your options, please get in touch with our sales team at 01535 500901.
Ideal Applications
Commonly installed across commercial, residential and public-sector sites.
-
Residential Driveways
-
Commercial Buildings
-
Schools
-
Business Parks
-
Warehouses
-
Retail Parks
-
Private Estates
Why Choose This Product?
Practical advantages that matter on real sites.
-
Heavy-duty construction
Built with reinforced steel for long-term outdoor performance.
-
Low maintenance
Designed to minimise service intervals and ongoing costs.
-
Reliable daily operation
Tested for thousands of cycles in high-traffic environments.
-
Suitable for high-traffic locations
Trusted in car parks, retail parks and commercial estates.
-
Professional UK installation available
Nationwide fitting by our accredited engineers.
Product Media
Watch product and installation videos, and browse real project photography.
Project Images
Our Installation Process
A clear, structured journey from first contact to fully operational site.
-
1
Request Quote
Tell us about your site and we will prepare a tailored quotation.
-
2
Technical Consultation
Our team reviews specifications, regulations and traffic patterns.
-
3
Site Survey
An engineer visits to confirm ground conditions and layout.
-
4
Professional Installation
Accredited installers complete the work to manufacturer standards.
-
5
Testing & Handover
Full operational test, signage check and on-site training.
Technical Specifications
Key performance and build details for this model.
| Security Rating | (BSI PAS68:2010) V/7500(N2)/64/90:2.8/7.2TESTED |
|---|---|
| Application | High Risk Areas |
| Minimum Shroud Measurements | 1500mm (l) X 460mm (w) X 930mm (h) as standard |
| Minimum Planting Depth | 200mm |
| Height (above ground) | 900mm |
| Tested Core Dimensions | 100mm (w) X 190mm (l) X 900mm (h) from FFL |
| Minimum Array | One |
| Shroud Material | Grade 316 satin polished stainless steel as standard |
| RAL Colours | All standard RAL colurs are available |
| Foundation Depth | 200mm |
| Warranty | 12 month for product and installation |
Compare Similar Bollards
Side-by-side comparison of similar products in the same category.
| Image | Model | Height | Diameter | Type | Best Application | Warranty | Installation |
|---|---|---|---|---|---|---|---|
|
|
Shallow Mount Planter 40 – Crash Tested to stop a 7500kg vehicle @ 40mph Current model | 900mm | High Risk Areas | 12 month for product and installation | Installation available | ||
|
Surface Mounted Crash Block – Crash Tested to stop a 7500kg vehicle @ 30mph, 40mph & 50mph | Surface mounted - free standing | High Risk Areas | 12 month for product and installation | Installation available | ||
|
Surface Mount Crash Bench – Crash Tested to stop a 7500kg vehicle @ 40mph | High Risk Areas | 12 month for product and installation | Installation available | |||
|
Truck Stopper 5-50 Shallow Mount PAS68 Bollard – Crash Tested to stop a 7500kg vehicle @ 50mph | 1050mm | Root fixed in concrete using compliant rebar cage | High Risk Areas | 12 month for product and installation | Installation available |
Trusted Reviews
What customers say about Shallow Mount Planter 40 - Crash Tested to stop a 7500kg vehicle @ 40mph and Bollard Security
Frequently Asked Questions
Common buying questions answered up front.
-
Most automatic bollard installations are completed within one working day once the site has been surveyed and prepared.
-
We recommend a scheduled service visit every 12 months to keep your bollard operating reliably and to validate the warranty.
-
All our automatic bollards come with a manufacturer-backed warranty. See the product Downloads section for the full document.
-
Stocked models typically install within 5 working days. Bespoke orders depend on specification and are quoted per project.
-
Most automatic bollards integrate with standard access control systems. Contact us with your existing setup and we will confirm compatibility.
-
Automatic bollards are commonly installed on driveways, commercial entrances, car parks, retail parks, schools and private estates.
Need Help Choosing?
Speak to our team before you decide.
Ready to secure your property?
Request a free quote or speak to our team. We will help you choose the right bollard for your site.
